Description
|
Product Model |
JF-ES-1500A |
JF-ES-1500B |
|
Capacity |
12V180Ah 2000Wh |
12V 135 Ah 1500Wh |
|
Output Power |
Rated:1300W, Max:1500W |
Rated: 1300W, Max:1500W |
|
Input Voltage |
AC 110V-220V 50/60Hz |
AC 110V-220V 50/60Hz |
|
Output Voltage |
220V 50Hz/110V60Hz |
220V 50Hz/110V60Hz |
|
DC Output |
24V/5A 5V/2A |
24V/5A 5V/2A |
|
LED lights |
1W, Max 3W |
1W, Max 3W |
|
Solar Charge |
36V 500-800W |
36V 500-800W |
|
Output Waveform |
Pure sine wave
|
Pure sine wave
|
|
Power failure response time
|
≤5 millisecond |
≤5 millisecond |
|
Overload |
When the overload occurs, the AC output is disconnected the indicator light turns into red, the load is disconnected, restart the battery. |
When the overload occurs, the AC output is disconnected, the indicator light turns into red, the load is disconnected, restart the battery. |
|
Short Circuit |
When the short circuit occurs, the AC output and the load is disconnected, restart the battery. |
When the short circuit occurs, the AC output and the load is disconnected, restart the battery. |
|
Charge Time |
14-15h |
11-12h |
|
Weight |
16kg |
14.5kg |
|
Product Dimensions |
42.3*17.5*23cm |
42.3*17.5*23cm |
|
Color |
Black |
Black |
